所有尺寸技术要求可以根据客户要求设计制造
输出电缆:多重接触连接器
二极管:10A, 100V旁路肖特基二极管
结构:正面为3.2mm高透光率的低铁刚化绒面玻璃，背材为TPT，胶膜为EVA
框架:型号为6063T5，镀氧化膜铝合金 |
| 组件型号 |
峰值功率
(WP) |
开路电压
(V) |
工作电压
(V) |
短路电流
(A) |
工作电流
(A) |
外形尺寸
(mm) |
重量
(Kg) |
KM240(48)1580×1060×50㎜ |
240W |
59.7V |
48.54V |
5.42A |
4.84A |
1580×1060×50 |
20.3㎏ |
KM220(48)1580×1060×50㎜ |
220W |
58.6V |
48.32V |
5.00A |
4.55A |
1580×1060×50 |
20.3㎏ |
KM200(48)1580×1060×50㎜ |
200W |
57.9V |
47.8V |
4.68A |
4.18A |
1580×1060×50 |
20.3㎏ |
KM180(34)1580×808×50㎜ |
180W |
44.3V |
35.6V |
5.57A |
5.05A |
1580×808×50 |
15.7㎏ |
KM175(34)1580×808×50㎜ |
175W |
43.8V |
35.3V |
5.45A |
4.96A |
1580×808×50 |
15.7㎏ |
KM170(34)1580×808×50㎜ |
170W |
43.5V |
35.3V |
5.29A |
4.81A |
1580×808×50 |
15.7㎏ |
KM165(34)1580×808×50㎜ |
165W |
43.1V |
35.2V |
5.14A |
4.68A |
1580×808×50 |
15.7㎏ |
KM160(34)1580×808×50㎜ |
160W |
43.0V |
35.0V |
5.09A |
4.63A |
1580×808×50 |
15.7㎏ |
KM155(34)1580×808×50㎜ |
155W |
42.9V |
37.8V |
4.83A |
4.39A |
1580×808×50 |
15.7㎏ |
KM150(34)1580×808×50㎜ |
150W |
43.1V |
34.8V |
4.80A |
4.31A |
1580×808×50 |
15.7㎏ |
KM145(34)1580×808×50㎜ |
145W |
43.1V |
34.5V |
4.73A |
4.20A |
1580×808×50 |
15.7㎏ |
KM140(34)1580×808×50㎜ |
140W |
43.1V |
34.5V |
4.45A |
4.05A |
1580×808×50 |
15.7㎏ |
KM130(27)1210×808×35㎜ |
130W |
32.6V |
27.4V |
5.21A |
4.74A |
1210×808×35 |
10.5㎏ |
KM80(17)1210×550×35㎜ |
80W |
21.6V |
17.5V |
5.02A |
4.57A |
1210×550×35 |
7.8㎏ |
KM20(17)650×280×28㎜ |
20W |
21.3V |
17.1V |
1.27A |
1.16A |
650×280×28 |
2.6㎏ |
KM15(17)520×280×28㎜ |
15W |
21.2V |
17.1V |
0.95A |
0.87A |
520×280×28 |
1.8㎏ |
KM10(17)450×230×28㎜ |
10W |
21.1V |
17.1V |
0.63A |
0.58A |
450×230×28 |
1.5㎏ |
KM5(17)370×170×28㎜ |
5W |
21.1V |
17.1V |
0.32A |
0.29A |
370×170×28 |
0.9㎏ |
| 组件型号 |
L |
W |
A |
C |
D |
| KM240(48)1580×1060×50㎜ |
1580 |
1060 |
790 |
1020 |
6×8 |
| KM180(34)1580×808×50㎜ |
1580 |
808 |
790 |
768 |
6×8 |
| KM130(27)1210×808×35㎜ |
1210 |
808 |
605 |
768 |
6×8 |
| KM80(17)1210×550×35㎜ |
1210 |
550 |
605 |
520 |
6×8 |
| KM20(17)650×280×28㎜ |
650 |
280 |
325 |
260 |
6×8 |
| KM15(17)520×280×28㎜ |
520 |
280 |
260 |
500 |
6×8 |
| KM10(17)450×230×28㎜ |
450 |
230 |
225 |
210 |
6×8 |
| KM5(17)370×170×28㎜ |
370 |
170 |
185 |
150 |
6×8 |
|
 |
|
